Installation 01.04
5-4 Siemens AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
5.1.2 Converters: 3AC 400V and 575V, 60A to 280A, 1Q
s
350
283 265
230
15
385
3737108
129
1U1
V8
V7
V1+V4
T2 T3
R100
366
10
1D1 1V1 1C1 1W1
X300
XF1 XF2
100
1)
100
1)
V3+V6 V5+V2
for M8
for M6
17.5
271.5
12.5
48.548.5 48.5
1) Minimum clearance for air circulation
An adequate cooling air supply must be provided
Fan in devices
≥
210A only
1U1, 1V1, 1W1, 1C1, 1D1 = 13 Nm
= 25 Nm
Tightening torque for customer connections:
Max. conductor size for cables with cable eye
in accordance with DIN 46234: 2 x 95 mm
2
