Start-Up 05.05
7-52 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
7.7.7.1 Diagnostic tools:
LED displays on the CBD (steadily flashing LEDs indicate normal operation):
Red Status of CBD (software working correctly)
Yellow Communication between SIMOREG and CBD
Green PZD data exchange between CBD and DeviceNet
LED
red yellow green
Status
flashing flashing flashing Normal operation
flashing off on CBD waiting for commencement of initialization by SIMOREG
flashing on off CBD waiting for end of initialization by SIMOREG
flashing flashing off No PZD data exchange via DeviceNet
flashing on on CBD defective
Diagnostic parameter n732:
Indices i001 to i032 apply to a CBD as the first communication board, while indices i033 to i064
apply to a CBD as the second communication board.
Value Meaning
n732.001
or
n732.033
0
1
2
3
17
Ok
Fault F080/fault value 5 is displayed under fault conditions:
DeviceNet MAC ID (P918 / slave address) incorrect
DeviceNet polled I/O produced connection path (U711) incorrect
DeviceNet polled I/O produced consumed path (U712) incorrect
Baud rate (U720) incorrect
n732.002
or
n732.034
The displayed decimal values must be converted to hexadecimal values. In hexadecimal
notation, every digit of the 16-bit data word has a meaning:
Bit8Bit9Bit10Bit11Thousands place Units placeTens place
Thousands place:
(Idle Indicator)
0 = device not idle; A
poll or bit strobe
request with length
other than 0 was last
received
1 = device idle; A
poll or bit strobe
request with length
equal to 0 was last
received
Hundreds place:
(Channel Allocation)
The meaning of
individual bits is as
follows
Bit8: 1 = Explicit
Channel allocated
Bit9: 1 = I/O Poll
Channel allocated
Bit10: 1 = I/O Bit
Strobe Channel
allocated
Bit11: 1 = Reserved
Tens place:
Reserved
Units place:
(network status)
0 = CBD not online
(Dup_MAC_ID test
not yet complete)
1 = CBD online, but
not assigned to a
master
2 = CBD online and
assigned to the
master
3 = data cannot be
exchanged via bus
(multiple MAC IDs or
Bus Off)
n732.003
or
n732.035
Number of correctly received telegrams since Power ON. The value contains all Group2
DeviceNet messages including those that are not addressed to this CBD.
n732.008
or
n732.040
Number of correctly received PZD telegrams since Power ON
n732.009
or
n732.041
Number of Bus Off states since Power ON (alarm A084)
n732.019
or
n732.051
Number of correctly transmitted telegrams since Power ON
n732.026
or
n732.058
Software version of CBDs
( e.g. "12“ = Version 1.2, see also r060)
