Siemens 6RA7086-6KS22

Function diagrams 05.05
8-84 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Sheet B158 Derivative / delay elements (LEAD / LAG blocks)
87564321
- B158 -
278 279
T1
Tv
.09
.09
.09
.10
.10
.10
T1
Tv
U550 (0)
K K9408
U553 (1)
K
U554.09 (100ms)
U551 (1)
K
U552.09 (100ms)
U550 (0)
K
K9409
U553 (1)
K
U554.10 (100ms)
U551 (1)
K
U552.10 (100ms)
0...10000ms
1...10000ms
0...10000ms
1...10000ms
2 LEAD / LAG blocks
Transfer function: 1 + sTv G(s) = --------- 1 + sT1
Derivative action time
Filter time
Derivative action time
Filter time
