Siemens 6RA7086-6KS22

Function diagrams 05.05
8-136 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Sheet Z151 SCB1 with SCI1 as slave 2: analog inputs
87564321
- Z151 -
X428
U
±10V
I
±20mA
1 2 3
4
5 6 7 8 9
10
11
3 4 4
5
<2> <2> <2>
<1> <1> <1>
<2>
<1>
U692.04(0) U691.04(2) n699.06
K4201
0...2
U690.04(0)
-20,00...20,00V 0...15
U692.05(0) U691.05(2) n699.07
K4202
0...2
U690.05(0)
-20,00...20,00V 0...15
U692.06(0) U691.06(2) n699.08
K4203
0...2
U690.06(0)
-20,00...20,00V 0...15
SCB1 with SCI1 as slave 2: analog inputs
Hardware-
Smoothing 1ms
Offset
Hardware-
Smoothing 1ms
Offset
Hardware-
Smoothing 1ms
Offset
+10 V / 5 mA for potentiometer, short-circuit-proof -10 V / 5 mA for potentiometer, short-circuit-proof
Smoothing
Smoothing Smoothing
Smoothing time constant T = 2 ms * 2
U691
U690 Voltage input Current input Kl. X428.3, .6, .9 Kl. X428.5, .8, .11 0 -10 ... 10 V -20 ... 20 mA 1 0 ... 10 V 0 ... 20 mA 2 - 4 ... 20 mA
Analog input 2 Analog input 3 Analog input 1 SCI Slave 2
Signal type Signal type Signal type
Signal type
12 bits + sign
12 bits + sign
12 bits + sign
A
D
A
D
A
D
Changes to parameters U690, U691 or U692 do not take effect until the system is reconfigured (e.g. using U710=0).
