Siemens 6RA7086-6KS22

Function diagrams 05.05
8-138 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Sheet Z156 SCB1 with SCI1 as slave 2: analog outputs
87564321
y
y [V] =
*
U694.04
x
100%
14 12
M
- Z156 -
X428
U
I
x
13
y
y [V] =
*
U694.05
x
100%
17 15
M
U
I
x
16
y
y [V] =
*
U694.06
x
100%
20 18
M
U
I
x
19
-100,00...+100,00V-320,00...+320,00V
U694.04 (10,00)
U693.04(0)
K
U695.04 (0,00)
n699.14
-100,00...+100,00V-320,00...+320,00V
U694.05 (10,00)
U693.05(0)
K
U695.05 (0,00)
n699.15
-100,00...+100,00V-320,00...+320,00V
U694.06 (10,00)
U693.06(0)
K
U695.06 (0,00)
n699.16
Iout = -20 ... 20 mA Iout = -20 ... 20 mA Iout = -20 ... 20 mA
Analog output 1
A
D
SCB1 with SCI1 as slave 2: analog outputs
Gain Offset
Analog output 2
A
D
Gain Offset
Analog output 3
A
D
Gain
Offset
Changes to parameters U694 or U695 do not take effect until the system is reconfigured (e.g. using U710=0).
