Siemens 6RA7086-6KS22

05.05 Function descriptions
SIEMENS AG 6RX1700-0AD76 9-49
SIMOREG DC Master Operating Instructions
6RA7082-6FS22 and 6RA7082-6FV62
Tp (s) Tp (s) Tp (s) Tp (s) Tp (s) Tp (s)
Ig (%) X=1.8 X=1.5 X=1.4 X=1.3 X=1.2 X=1.1
0 1.460 6.560 12.320 23.900 49.460 103.620
10 1.248 5.412 10.423 20.816 44.704 98.249
20 1.039 4.266 8.442 17.528 39.262 91.829
30 0.844 3.189 6.455 14.096 33.181 84.141
40 0.663 2.248 4.583 10.599 26.601 74.867 X t
an
(s)
50 0.495 1.512 2.959 7.189 19.783 63.575 1.1 109.8
60 0.344 0.980 1.736 4.192 13.053 49.724 1.2 49.0
70 0.213 0.587 0.959 2.008 6.836 33.160 1.3 22.4
80 0.110 0.289 0.460 0.847 2.353 15.936 1.4 11.1
90 0.032 0.090 0.138 0.248 0.542 2.830 1.5 5.7
94 0.014 0.051 0.083 0.149 0.320 0.947 1.8 1.3
98 0.005 0.018 0.029 0.051 0.110 0.325
100 0.000 0.001 0.001 0.002 0.005 0.014 t
ab
(s) = 206
6RA7082-6FS22 450A/1Q 460V
6RA7082-6FV62 450A/4Q 460V
0,1
1,0
10,0
100,0
1000,0
0 102030405060708090100
Base-load current as % of rated DC current
Overload period in s with cycle time of 300s
X=1,8
X=1,5
X=1,4
X=1,3
X=1,2
X=1,1
6RA7082-6FS22 450A/1Q 460V
6RA7082-6FV62 450A/4Q 460V
0
50
100
150
200
250
300
0 102030405060708090100
Base-load current as % of rated DC current
Overload period in s with cycle time of 300s
X=1,8
X=1,5
X=1,4
X=1,3
X=1,2
X=1,1
