05.05 Function descriptions
SIEMENS AG 6RX1700-0AD76 9-51
SIMOREG DC Master Operating Instructions
6RA7085-6DV62. 6RA7085-6FV62 and 6RA7085-6GV62
Tp (s) Tp (s) Tp (s) Tp (s) Tp (s) Tp (s)
Ig (%) X=1.8 X=1.5 X=1.4 X=1.3 X=1.2 X=1.1
0 6.320 34.420 55.620 86.300
133.680 219.660
10 4.768 29.728 50.173 80.420 127.741 215.465
20 3.249 24.577 43.899 73.524
120.691 210.355
30 2.016 19.130 36.764 65.460
112.287 203.997
40 1.293 13.684 28.809 56.012
102.199 196.025 X t
an
(s)
50 0.868 8.632 20.340 44.942 89.953 185.803 1.1 423.0
60 0.575 4.294 12.167 32.342 74.877 172.318 1.2 183.0
70 0.354 1.497 5.361 18.343 55.975 153.824 1.3 105.0
80 0.192 0.645 1.347 6.565 32.161 126.914 1.4 63.0
90 0.079 0.283 0.483 0.911 7.922 83.908 1.5 36.0
94 0.058 0.208 0.355 0.662 2.177 58.269 1.8 5.2
98 0.037 0.132 0.226 0.421 0.852 25.724
100 0.026 0.094 0.161 0.301 0.190 9.452 t
ab
(s) = 452
6RA7085-6DV62 600A/4Q 400V
6RA7085-6FV62 600A/4Q 460V
6RA7085-6GV62 600A/4Q 575V
0,1
1,0
10,0
100,0
1000,0
0 102030405060708090100
Base-load current as % of rated DC current
Overload period in s with cycle time of 300s
X=1,8
X=1,5
X=1,4
X=1,3
X=1,2
X=1,1
6RA7085-6DV62 600A/4Q 400V
6RA7085-6FV62 600A/4Q 460V
6RA7085-6GV62 600A/4Q 575V
0
50
100
150
200
250
300
0 102030405060708090100
Base-load current as % of rated DC current
Overload period in s with cycle time of 300s
X=1,8
X=1,5
X=1,4
X=1,3
X=1,2
X=1,1
