Siemens 6RA7086-6KS22

Parameter list 05.05
11-90 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
r810
(G170)
Receive data on G-SST1
Display of data received via USS interface 1
i001: Display process data word 1
...
i016 Display process data word 16
i017: Display parameter data word 1
...
i020: Display parameter data word 4
Ind: 20
Type: L2
P052 = 3
r811
(G170)
Transmit data on G-SST1
Display of the data to be transmitted via USS interface 1
i001: Display process data word 1
...
i016 Display process data word 16
i017: Display parameter data word 1
...
i020: Display parameter data word 4
Ind: 20
Type: L2
P052 = 3
r812
(G171)
(G173)
Receive data on G-SST2
When USS protocol (P790=2) is selected:
Display of data received via USS interface 2
i001: Display process data word 1
...
i016 Display process data word 16
i017: Display parameter data word 1
...
i020: Display parameter data word 4
When peer-to-peer (P790=5) is selected:
Display of data received via peer-to-peer interface 2
i001: Receive data word 1
...
i005 Receive data word 5
i006: Not used
...
i020 Not used
When communication with the SIMOREG CCP is selected (P790 = 6):
Data received from the SIMOREG CCP via interface 2 is displayed
i001: Last received 1-byte message
i002: Last received header of a multibyte message
...
i018 Free-running counter for the number of received 1-byte
messages
i019 Free-running counter for the number of received headers of a
multibyte message
i020 Free-running counter for the number of received sequence bytes
of a multibyte message
Ind: 20
Type: L2
P052 = 3
