Parameter list 05.05
11-132 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU
Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U341
(2341)
*
S00
(B205)
Source for input signals, AND element 22 (output = B9371) FB 141
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U342
(2342)
*
S00
(B205)
Source for input signals, AND element 23 (output = B9372) FB 142
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U343
(2343)
*
S00
(B205)
Source for input signals, AND element 24 (output = B9373) FB 143
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U344
(2344)
*
S00
(B205)
Source for input signals, AND element 25 (output = B9374) FB 144
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U345
(2345)
*
S00
(B205)
Source for input signals, AND element 26 (output = B9375) FB 145
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U346
(2346)
*
S00
(B205)
Source for input signals, AND element 27 (output = B9376) FB 146
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U347
(2347)
*
S00
(B205)
Source for input signals, AND element 28 (output = B9377) FB 147
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
OR elements with 3 inputs each
The input signals selected via the 3 indices of the parameter are ORed and the result of the logic operation applied to the specified
binector.
U350
(2350)
*
S00
(B206)
Source for input signals, OR element 1 (output = B9380) FB 150
i001 Source for input 1
i002 Source for input 2
i003 Source for input 3
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U351
(2351)
*
S00
(B206)
Source for input signals, OR element 2 (output = B9381) FB 151
As for U350
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U352
(2352)
*
S00
(B206)
Source for input signals, OR element 3 (output = B9382) FB 152
As for U350
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U353
(2353)
*
S00
(B206)
Source for input signals, OR element 4 (output = B9383) FB 153
As for U350
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U354
(2354)
*
S00
(B206)
Source for input signals, OR element 5 (output = B9384) FB 154
As for U350
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
