Siemens 6RA7086-6KS22

Parameter list 05.05
11-152 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
11.76 Setpoint reduction
U607
(2607)
*
BDS
(G135)
Source for activation of the setpoint reduction [SW 1.6 and later]
0 = Binector B0000
1 = Binector B0001
etc.
0 Setpoint reduction active
The Setpoint (before the ramp-function generator) is multiplied
by the factor set in parameter U608
1 No setpoint reduction
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
off-line
U608
(2608)
FDS
(G135)
Multiplier for speed setpoint on activation of the setpoint reduction[SW
1.6 and later]
0.00 to 100.00
[%]
0.01%
Ind: 4
FS=15.00
Type: O2
P052 = 3
P051 = 40
on-line
11.77 Definition of the function of inputs and outputs
U616
(2616)
(G117)
Control word for input "E stop" (term. 105 to 108) [SW 2.0 and later]
0 = E stop has same effect as OFF2
1 = E stop immediately cancels the firing pulse chain (without waiting for
I = 0 and without outputting
α
w
)
0 to 1
1
Ind: none
FS=0
Type: O2
P052 = 3
P051 = 40
online
11.78 Definition of the function of the relay output at terminals 109 / 110
U619
(2619)
*
BDS
(G117)
Source for the relay output "line contactor ON" (terminals 109 / 110)
[SW 1.7 and later]
0 = Binector B0000
1 = Binector B0001
etc.
124 = Main contactor ON
All binector numbers
1
Ind: 2
FS=124
Type: L2
P052 = 3
P051 = 40
off-line
11.79 Starting pulse – Speed controller
(See also Chapter 8 Function Diagram Sheet G150)
U651
(2651)
FDS
(G150)
Starting pulse (integrator setting value for the speed controller)
[SW 1.7 and later]
-100.00 to 100.00
[%]
0.01%
Ind: 4
FS=0.00
Type: I2
P052 = 3
P051 = 40
on-line
U652
(2652)
FDS
(G150)
Multiplier for starting pulse with neg. setpoint [SW 1.7 and later]
if the starting pulse acc. to U651 is also used for pos. setpoint
0.00 to 200.00
[%]
0.01%
Ind: 4
FS=50.00
Type: O2
P052 = 3
P051 = 40
on-line
U653
(2653)
FDS
(G150)
Starting pulse with neg. setpoint [SW 1.7 and later]
-100.00 to 100.00
[%]
0.01%
Ind: 4
FS=0.00
Type: I2
P052 = 3
P051 = 40
on-line
U655
(2655)
*
(G150)
Source for Starting pulse [SW 1.7 and later]
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: None
FS=451
Type: L2
P052 = 3
P051 = 40
off-line
U656
(2656)
*
(G150)
Source for starting pulse with neg. setpoint [SW 1.7 and later]
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: None
FS=452
Type: L2
P052 = 3
P051 = 40
off-line
U657
(2657)
*
BDS
(G150)
Source for switchover starting pulse for pos./neg. setp.
[SW 1.7 and later]
0 = Binector B0000
1 = Binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
