Siemens 6RA7086-6KS22

05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-167
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U766
(2766)
(Z113)
(Z116)
Normalization of analog outputs on EB1 [SW 1.5 and later]
%100
766U
x]V[y ∗=
x = normalization input (corresponds to filtering output)
y = normalization output (corresponds to output voltage at analog output
with an offset of 0)
i001: AO1 of the first EB1
i002: AO2 of the first EB1
i003: AO1 of the second EB1
i004: AO2 of the second EB1
-200.00 to 199.99
[V]
0.01V
Ind: 4
WE=10,00
Typ: I2
P052 = 3
P051 = 40
on-line
U767
(2767)
(Z113)
(Z116)
Offset for analog outputs on EB1 [SW 1.5 and later]
i001: AO1 of the first EB1
i002: AO2 of the first EB1
i003: AO1 of the second EB1
i004: AO2 of the second EB1
-10.00 to 10.00
[V]
0.01V
Ind: 4
WE=0,00
Typ: I2
P052 = 3
P051 = 40
on-line
n768
(2768)
(Z113)
(Z116)
Display of analog outputs on EB1 [SW 1.5 and later]
i001: AO1 of the first EB1
i002: AO2 of the first EB1
i003: AO1 of the second EB1
i004: AO2 of the second EB1
-200.0 to 199.99
[%]
0.01%
Ind: 4
Typ: I2
P052 = 3
U769
(2769)
*
(Z114)
(Z117)
Source for output values at binary outputs on EB1 [SW 1.5 and later]
Selection of binectors to be applied to binary outputs at terminals 43 - 46.
0 = Binector B0000
1 = Binector B0001
etc.
i001: BO1 of the first EB1
i002: BO2 of the first EB1
i003: BO3 of the first EB1
i004: BO4 of the first EB1
i005: BO1 of the second EB1
i006: BO2 of the second EB1
i007: BO3 of the second EB1
i008: BO4 of the second EB1
All binector numbers
1
Ind: 8
WE=0
Typ: L2
P052 = 3
P051 = 40
off-line
n770
(2770)
(Z114)
(Z117)
Display of status of binary inputs and outputs on EB1
[SW 1.5 and later]
Representation on operator panel (PMU):
32104
5
6
Segment ON: Corresponding terminal is activated
(HIGH level is applied)
Segment OFF: Corresponding terminal is not activated
(LOW level is applied)
Segment or bit
0 ....... Terminal 40
1 ....... Terminal 41
2 ....... Terminal 42
3 ....... Terminal 43
4 ....... Terminal 44
5 ....... Terminal 45
6 ....... Terminal 46
i001: Terminal states of first EB1
i002: Terminal states of second EB1
Ind: 2
Typ: V2
P052 = 3
