05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-7
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
K0289
EMF setpoint
16384
=
∧
P078.001
*
32
π
G165
K0290
Motor flux
16384
=
∧
100%
100% motor flux is reached
at rated motor field current
(P102)
G166
K0291
Absolute actual armature voltage
16384
=
∧
P078.001
*
32
π
K0292
Signed actual armature voltage
16384
=
∧
P078.001
*
32
π
K0293
Precontrol output (EMF)
16384
=
∧
100%
G165
General connectors
K0301
Line voltage U-V (armature)
16384
=
∧
P078.001
K0302
Line voltage V-W (armature)
16384
=
∧
P078.001
K0303
Line voltage W-U (armature)
16384
=
∧
P078.001
K0304
Line voltage (field)
16384
=
∧
400V
K0305
Average line voltage (armature), filtered
16384
=
∧
P078.001
K0306
Line frequency
16384
=
∧
50.0Hz
K0307
Motor power output
Normalization:
16384
=
∧
P100 * (P101 – P100 * P110)
see Column 2
K0309
Calculated motor temperature rise
Normalization:
16384
=
∧
the overtemperature which is reached at a
continuous current corresponding to the rated motor armature
current
see Column 2
K0310
Calculated thyristor temperature rise as % of maximum permissible thyristor
temperature rise
16384
=
∧
100%
K0311
Hours run [SW 1.9 and later]
1
=
∧
1h
G189
Fixed setpoints
K0401
Fixed value 1 (P401)
16384
=
∧
100%
G120
K0402
Fixed value 2 (P402)
16384
=
∧
100%
G120
K0403
Fixed value 3 (P403)
16384
=
∧
100%
G120
K0404
Fixed value 4 (P404)
16384
=
∧
100%
G120
K0405
Fixed value 5 (P405)
16384
=
∧
100%
G120
K0406
Fixed value 6 (P406)
16384
=
∧
100%
G120
K0407
Fixed value 7 (P407)
16384
=
∧
100%
G120
K0408
Fixed value 8 (P408)
16384
=
∧
100%
G120
K0409
Fixed value 9 (P409)
16384
=
∧
100%
G120
K0410
Fixed value 10 (P410)
16384
=
∧
100%
G120
K0411
Fixed value 11 (P411)
16384
=
∧
100%
G120
K0412
Fixed value 12 (P412)
16384
=
∧
100%
G120
K0413
Fixed value 13 (P413)
16384
=
∧
100%
G120
K0414
Fixed value 14 (P414)
16384
=
∧
100%
G120
K0415
Fixed value 15 (P415)
16384
=
∧
100%
G120
K0416
Fixed value 16 (P416)
16384
=
∧
100%
G120
Start pulse for the speed controller [SW 1.7 and later]
K0451
Fixed setting value 1 for the n controller I component
16384
=
∧
100% of P100
G150
K0452
Setting value 1 for the n controller I component, weighted
16384
=
∧
100% of P100
G150
K0453
Fixed setting value 2 for the n controller I component
16384
=
∧
100% of P100
G150
