Siemens 6RA7086-6KS22

05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-25
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
K9573
Fixed value 73 (U099.73) [SW 1.8 and later]
16384
=
∧
100%
B110
K9574
Fixed value 74 (U099.74) [SW 1.8 and later]
16384
=
∧
100%
B110
K9575
Fixed value 75 (U099.75) [SW 1.8 and later]
16384
=
∧
100%
B110
K9576
Fixed value 76 (U099.76) [SW 1.8 and later]
16384
=
∧
100%
B110
K9577
Fixed value 77 (U099.77) [SW 1.8 and later]
16384
=
∧
100%
B110
K9578
Fixed value 78 (U099.78) [SW 1.8 and later]
16384
=
∧
100%
B110
K9579
Fixed value 79 (U099.79) [SW 1.8 and later]
16384
=
∧
100%
B110
K9580
Fixed value 80 (U099.80) [SW 1.8 and later]
16384
=
∧
100%
B110
K9581
Fixed value 81 (U099.81) [SW 1.8 and later]
16384
=
∧
100%
B110
K9582
Fixed value 82 (U099.82) [SW 1.8 and later]
16384
=
∧
100%
B110
K9583
Fixed value 83 (U099.83) [SW 1.8 and later]
16384
=
∧
100%
B110
K9584
Fixed value 84 (U099.84) [SW 1.8 and later]
16384
=
∧
100%
B110
K9585
Fixed value 85 (U099.85) [SW 1.8 and later]
16384
=
∧
100%
B110
K9586
Fixed value 86 (U099.86) [SW 1.8 and later]
16384
=
∧
100%
B110
K9587
Fixed value 87 (U099.87) [SW 1.8 and later]
16384
=
∧
100%
B110
K9588
Fixed value 88 (U099.88) [SW 1.8 and later]
16384
=
∧
100%
B110
K9589
Fixed value 89 (U099.89) [SW 1.8 and later]
16384
=
∧
100%
B110
K9590
Fixed value 90 (U099.90) [SW 1.8 and later]
16384
=
∧
100%
B110
K9591
Fixed value 91 (U099.91) [SW 1.8 and later]
16384
=
∧
100%
B110
K9592
Fixed value 92 (U099.92) [SW 1.8 and later]
16384
=
∧
100%
B110
K9593
Fixed value 93 (U099.93) [SW 1.8 and later]
16384
=
∧
100%
B110
K9594
Fixed value 94 (U099.94) [SW 1.8 and later]
16384
=
∧
100%
B110
K9595
Fixed value 95 (U099.95) [SW 1.8 and later]
16384
=
∧
100%
B110
K9596
Fixed value 96 (U099.96) [SW 1.8 and later]
16384
=
∧
100%
B110
K9597
Fixed value 97 (U099.97) [SW 1.8 and later]
16384
=
∧
100%
B110
K9598
Fixed value 98 (U099.98) [SW 1.8 and later]
16384
=
∧
100%
B110
K9599
Fixed value 99 (U099.99) [SW 1.8 and later]
16384
=
∧
100%
B110
K9600
Fixed value 100 (U099.100) [SW 1.8 and later]
16384
=
∧
100%
B110
General connectors
K9801
Alarm word 1 (= parameter r953)
K9802
Alarm word 2 (= parameter r954)
K9803
Alarm word 3 (= parameter r955)
K9804
Alarm word 4 (= parameter r956)
K9805
Alarm word 5 (= parameter r957)
K9806
Alarm word 6 (= parameter r958)
K9807
Alarm word 7 (= parameter r959)
K9808
Alarm word 8 (= parameter r960)
K9811
Fault number 1 (= parameter r947.01, current fault number) G189
K9812
Fault number 2 (= parameter r947.09, second last fault number) G189
K9813
Fault number 3 (= parameter r947.17, third last fault number) G189
K9814
Fault number 4 (= parameter r947.25, fourth last fault number) G189
K9815
Fault number 5 (= parameter r947.33) G189
K9816
Fault number 6 (= parameter r947.41) G189
K9817
Fault number 7 (= parameter r947.49) G189
K9818
Fault number 8 (= parameter r947.57) G189
K9990
Current total processor capacity utilization (C163) (= parameter n009.01)
K9991
Projected total processor capacity utilization (C163) for line frequency =
65Hz (= parameter n009.02)
