Connectors and binectors 05.05
12-30 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B0195
Current limitation: Negative current limit reached [SW 1.8 and later] G161
B0196
α
G
limit reached [SW 1.8 and later]
G163
B0197
α
W
limit reached [SW 1.8 and later]
G163
B0198
Any positive limit (speed, torque, armature,
α
G
) reached [SW 2.0 and later]
B0199
Any positive limit (speed, torque, armature,
α
W
) reached [SW 2.0 and later]
B0200
Current limitation active G161
B0201
Speed limiting controller active G160
B0202
Upper torque limitation active G160
B0203
Lower torque limitation active G160
B0204
Torque or current limitation active or current controller at limitation G163
Speed controller
B0205
Speed controller enabling by sequencing control G152
Setpoint processing, ramp-function generator
B0206
Limitation after ramp-function generator (setpoint limitation) has responded G137
B0207
Ramp-function generator output = 0 (y = 0) G136
B0208
Ramp-function generator, ramp-up G136
B0209
Ramp-function generator, ramp-down G136
B0210
1 = no direction of rotation enabled G135
B0211
Ramp-function generator: Enable setpoint (1 = setpoint enabled) [SW 1.6 and later] G136
Limit-value monitor for field current
B0215
Limit-value signal I
f
< I
f min
(see P394, P395) G188
B0216
Limit-value signal I
f
< I
f x
(see P398, P399) G188
Armature gating unit
B0220
Enabled torque direction for parallel drive G163
B0221
1 = Torque direction I active G163
B0222
1 = Torque direction II active G163
B0225
1 = active paralleling master [SW 2.1 and later] G195
B0230
1 = No torque direction requested [SW 2.1 and later] G163
B0231
1 = Torque direction I requested [SW 2.1 and later] G163
B0232
1 = Torque direction II requested [SW 2.1 and later] G163
Motorized potentiometer
B0240
Motorized potentiometer output = 0 (y = 0) G126
B0241
Ramp-up/ramp-down finished (y = x) G126
Brake control
B0250
Brake control (1=close brake, 0=release brake) G140
B0251
1=auxiliaries ON, 0=auxiliaries OFF s.Chap. 9.10
B0252
1=device fan on, 0=device fan off [SW 1.5 and later]
B0255
B0250 inverted
[SW 1.4 and later] G140
B0256
B0251 inverted
[SW 1.5 and later]
Field reversal
B0260
1=Close field contactor 1 (control command for one contactor for connection of positive field direction) G200
B0261
1=Close field contactor 2 (control command for one contactor for connection of negative field direction) G200
