Siemens 6RA7086-6KS22

Connectors and binectors 05.05
12-32 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Binector Name, description Function
diag., Sheet
B2303
USS1 receive data, word 3, bit 3 G170
B2304
USS1 receive data, word 3, bit 4 G170
B2305
USS1 receive data, word 3, bit 5 G170
B2306
USS1 receive data, word 3, bit 6 G170
B2307
USS1 receive data, word 3, bit 7 G170
B2308
USS1 receive data, word 3, bit 8 G170
B2309
USS1 receive data, word 3, bit 9 G170
B2310
USS1 receive data, word 3, bit 10 G170
B2311
USS1 receive data, word 3, bit 11 G170
B2312
USS1 receive data, word 3, bit 12 G170
B2313
USS1 receive data, word 3, bit 13 G170
B2314
USS1 receive data, word 3, bit 14 G170
B2315
USS1 receive data, word 3, bit 15 G170
B2400
USS1 receive data, word 4, bit 0 G170
B2401
USS1 receive data, word 4, bit 1 G170
B2402
USS1 receive data, word 4, bit 2 G170
B2403
USS1 receive data, word 4, bit 3 G170
B2404
USS1 receive data, word 4, bit 4 G170
B2405
USS1 receive data, word 4, bit 5 G170
B2406
USS1 receive data, word 4, bit 6 G170
B2407
USS1 receive data, word 4, bit 7 G170
B2408
USS1 receive data, word 4, bit 8 G170
B2409
USS1 receive data, word 4, bit 9 G170
B2410
USS1 receive data, word 4, bit 10 G170
B2411
USS1 receive data, word 4, bit 11 G170
B2412
USS1 receive data, word 4, bit 12 G170
B2413
USS1 receive data, word 4, bit 13 G170
B2414
USS1 receive data, word 4, bit 14 G170
B2415
USS1 receive data, word 4, bit 15 G170
B2500
USS1 receive data, word 5, bit 0 G170
B2501
USS1 receive data, word 5, bit 1 G170
B2502
USS1 receive data, word 5, bit 2 G170
B2503
USS1 receive data, word 5, bit 3 G170
B2504
USS1 receive data, word 5, bit 4 G170
B2505
USS1 receive data, word 5, bit 5 G170
B2506
USS1 receive data, word 5, bit 6 G170
B2507
USS1 receive data, word 5, bit 7 G170
B2508
USS1 receive data, word 5, bit 8 G170
B2509
USS1 receive data, word 5, bit 9 G170
B2510
USS1 receive data, word 5, bit 10 G170
B2511
USS1 receive data, word 5, bit 11 G170
B2512
USS1 receive data, word 5, bit 12 G170
B2513
USS1 receive data, word 5, bit 13 G170
B2514
USS1 receive data, word 5, bit 14 G170
B2515
USS1 receive data, word 5, bit 15 G170
B2600
USS1 receive data, word 6, bit 0 G170
B2601
USS1 receive data, word 6, bit 1 G170
B2602
USS1 receive data, word 6, bit 2 G170
B2603
USS1 receive data, word 6, bit 3 G170
B2604
USS1 receive data, word 6, bit 4 G170
