Binector Name, description Function
diag., Sheet
B2907
USS1 receive data, word 9, bit 7 G170
B2908
USS1 receive data, word 9, bit 8 G170
B2909
USS1 receive data, word 9, bit 9 G170
B2910
USS1 receive data, word 9, bit 10 G170
B2911
USS1 receive data, word 9, bit 11 G170
B2912
USS1 receive data, word 9, bit 12 G170
B2913
USS1 receive data, word 9, bit 13 G170
B2914
USS1 receive data, word 9, bit 14 G170
B2915
USS1 receive data, word 9, bit 15 G170
Process data exchange with 1
st
CB/TB
B3030
Fault delay timeout for 1
st
CB/TB - maintained signal Z110
B3031
Fault delay timeout for 1
st
CB/TB - 1s pulse Z110
B3035
Telegram failure timeout for 1
st
CB/TB [SW 1.9 and later] Z110
Process data exchange with 1
st
CB/TB
B3100
Receive data from 1
st
CB/TB, word 1, bit 0 Z110
B3101
Receive data from 1
st
CB/TB, word 1, bit 1 Z110
B3102
Receive data from 1
st
CB/TB, word 1, bit 2 Z110
B3103
Receive data from 1
st
CB/TB, word 1, bit 3 Z110
B3104
Receive data from 1
st
CB/TB, word 1, bit 4 Z110
B3105
Receive data from 1
st
CB/TB, word 1, bit 5 Z110
B3106
Receive data from 1
st
CB/TB, word 1, bit 6 Z110
B3107
Receive data from 1
st
CB/TB, word 1, bit 7 Z110
B3108
Receive data from 1
st
CB/TB, word 1, bit 8 Z110
B3109
Receive data from 1
st
CB/TB, word 1, bit 9 Z110
B3110
Receive data from 1
st
CB/TB, word 1, bit 10 Z110
B3111
Receive data from 1
st
CB/TB, word 1, bit 11 Z110
B3112
Receive data from 1
st
CB/TB, word 1, bit 12 Z110
B3113
Receive data from 1
st
CB/TB, word 1, bit 13 Z110
B3114
Receive data from 1
st
CB/TB, word 1, bit 14 Z110
B3115
Receive data from 1
st
CB/TB, word 1, bit 15 Z110
B3200
Receive data from 1
st
CB/TB, word 2, bit 0 Z110
B3201
Receive data from 1
st
CB/TB, word 2, bit 1 Z110
B3202
Receive data from 1
st
CB/TB, word 2, bit 2 Z110
B3203
Receive data from 1
st
CB/TB, word 2, bit 3 Z110
B3204
Receive data from 1st CB/TB, word 2, bit 4 Z110
B3205
Receive data from 1
st
CB/TB, word 2, bit 5 Z110
B3206
Receive data from 1
st
CB/TB, word 2, bit 6 Z110
B3207
Receive data from 1
st
CB/TB, word 2, bit 7 Z110
B3208
Receive data from 1
st
CB/TB, word 2, bit 8 Z110
B3209
Receive data from 1
st
CB/TB, word 2, bit 9 Z110
B3210
Receive data from 1
st
CB/TB, word 2, bit 10 Z110
B3211
Receive data from 1
st
CB/TB, word 2, bit 11 Z110
B3212
Receive data from 1
st
CB/TB, word 2, bit 12 Z110
B3213
Receive data from 1
st
CB/TB, word 2, bit 13 Z110
B3214
Receive data from 1
st
CB/TB, word 2, bit 14 Z110
B3215
Receive data from 1
st
CB/TB, word 2, bit 15 Z110
B3300
Receive data from 1
st
CB/TB, word 3, bit 0 Z110
B3301
Receive data from 1
st
CB/TB, word 3, bit 1 Z110
