Siemens 7UT51

7UT51 v3
Binary-Signal Inputs, Signal Contacts, Trip Contacts, and LED Indicators
13
PRIM-2330C 127
13.3 Signal Output Contacts
13.3.1 Programmable Signal Contacts
Signal contact outputs enable the relay to send signals
to other devices by closing (or opening) the
connection between a pair of terminals. Each signal
contact output is controlled by up to twenty functions
selected from Table 6.x. The 7UT512 relay has four
contact outputs and the 7UT513 relay has ten contact
outputs. If desired, a function can activate more than
one signal contact relay.
Alarm functions have effect only when the
corresponding protection function is enabled and
active. Functions with a “>” sign prefix can be
assigned to both signal contact inputs and signal
contact outputs to pass a signal through the relay
independent of the relay’s protective functions (of
course, the relay must be operational).
>BU50HS BLK
>BU50/51 BLK
2306
2307
Block 50HS stage of backup O/C
Block 50/51 stage of backup O/C
>Ext1 BLOCK
>Ext1 blkTRIP
>Ext1 TRIP
4523
4525
4526
External Trip 1 signal (received through another signal input) will be blocked, will be
blocked from causing a trip ( ), or will be issued by a signal to this discrete input ( ).
>Ext2 BLOCK
>Ext2 blkTRIP
>Ext2 TRIP
4543
4545
4546
BLOCK external trip 2
BLOCK trip signal of external trip 2
External trip 2
>87Diff BLOCK
>87DiffBlkTrip
5603
5605
BLOCK differential protection
BLK differential prot. trip signal
>RGF BLOCK
>RGF blk Trip
5803
5805
Block restricted ground
-
fault protect
Block trip of restricted ground
-
fault
>Tank BLOCK
>Tank blkTrip
5903
5905
Block transformer tank protect
Block transformer tank protect trip signal
LCD
Abbreviation
Event Effect of Input Signal
7UT513 Only
6201 SIGNAL CONTACT 1 6206 SIGNAL CONTACT 6
6202 SIGNAL CONTACT 2 6207 SIGNAL CONTACT 7
6203 SIGNAL CONTACT 3 6208 SIGNAL CONTACT 8
6204 SIGNAL CONTACT 4 6209 SIGNAL CONTACT 9
6205 SIGNAL CONTACT 5 6210 SIGNAL CONTACT 10
6211 SIGNAL CONTACT 11
Each signal relay can be independently activated by up to twenty (20) functions (chosen from the
list in section Table 13.1). The default configuration is listed below:
Relay Code Function(s) Description
Relay 1 511 Device Trip General trip signal
Relay 2 5671 Diff Gen Trip Trip of differential protection
Relay 3 2451 Back Gen Trip Trip of backup overcurrent time protection
