15
Operation Using a Personal Computer
7UT51 v3
156 PRIM-2330C
Address 7831 – State of external trip function 2
Address 7885 – Select settings group
Address 7899 – Rated Frequency
15.3.2 Marshalling Menu
The marshalling menu allows the users to program all
of the relay inputs, outputs, and LED indicators.
Configuration of Discrete Inputs
(Address Block 6100)
Address 6101 – Configuration of Discrete Input 1
Address 6102 – Configuration of Discrete Input 2
Address 6103 – Configuration of Discrete Input 3
Address 6104 – Configuration of Discrete Input 4
Address 6105 – Configuration of Discrete Input 5
Configuration of Signal Relays
(Address Block 6200)
Address 6201 – Configuration of signal relay 1
Address 6202 – Configuration of signal relay 2
Address 6203 – Configuration of signal relay 3
Address 6204 – Configuration of signal relay 4
Address 6205 – Configuration of signal relay 5
Address 6206 – Configuration of signal relay 6
Address 6207 – Configuration of signal relay 7
Address 6208 – Configuration of signal relay 8
Address 6209 – Configuration of signal relay 9
Address 6210 – Configuration of signal relay 10
Address 6211 – Configuration of signal relay 11
Configuration of LED Indicators
(Address Block 6300)
Address 6301 – Configuration of LED 1
Address 6302 – Configuration of LED 2
Address 6303 – Configuration of LED 3
Address 6304 – Configuration of LED 4
Address 6305 – Configuration of LED 5
Address 6306 – Configuration of LED 6
Address 6307 – Configuration of LED 7
Address 6308 – Configuration of LED 8
Address 6309 – Configuration of LED 9
Address 6310 – Configuration of LED 10
Address 6311 – Configuration of LED 11
Address 6312 – Configuration of LED 12
Address 6313 – Configuration of LED 13
Address 6314 – Configuration of LED 14
Configuration of Trip Contacts
(Address Block 6400)
Address 6401 – Configuration of Trip Relay 1
Address 6402 – Configuration of Trip Relay 2
Address 6403 – Configuration of Trip Relay 3
Address 6404 – Configuration of Trip Relay 4
Address 6405 – Configuration of Trip Relay 5
15.3.3 Settings Menu Example for
Transformer Protection
Transformer Data Example (Address Block 1100)
Address 1102 – Rated voltage of transformer
Winding 1
Address 1103 – Rated apparent power (VA) of
Winding 1
Address 1104 – Rated primary current of
Winding 1 CT
Address 1105 – Star-point formation of
Winding 1 CT
Address 1106 – Processing of Winding 1 zero
sequence current
Address 1107 – Rated prim. current of Winding 1
star-point CT
Address 1108 – Ground point formation of
Winding 1 star-point CT
Address 1121 – Vector group associated with
winding 2
Address 1122 – Rated voltage of transformer
winding 2
Address 1123 – Rated apparent power (VA) of
winding 2
