Siemens 7UT51

13
Binary-Signal Inputs, Signal Contacts, Trip Contacts, and LED Indicators
7UT51 v3
132 PRIM-2330C
13.7 Numerical Listing of User Definable Trip and Signal
Functions
The events listed below are the marshalling
possibilities for signal contact inputs, signal contact
outputs, trip contact outputs, and LEDs. Some events
are for transformer protection only and some are for
the 7UT513 only.
Note:
Annunciations with a leading “>” sign are
identical with those for binary inputs and signal
or trip outputs. They represent the direct
confirmation of the binary input and are
available as long as the corresponding binary
input is energized.
Event LCD Abbreviation Description
1not allocated
3 >Time Synch Clock
-
synchronizing binary
-
signal input actuated.
4 >Trig. wave Trigger waveform capture
5 >Reset LEDs Reset LEDs
7
8
>ParamSelec.1
>ParamSelec.2
Change the
active parameter set
(must be used with a pair of binary
inputs, see Table 14.1 on page 144) when input becomes active.
11
12
13
14
>UsrDefEvent1
>UsrDefEvent2
>UsrDefEvent3
>UsrDefEvent4
>User defined event 1
>User defined event 2
>User defined event 3
>User defined event 4
51 Relay OK Relay is operational and protecting (cannot be changed)
95
96
97
98
99
SetChg inProg
Set Group A
Set Group B
Set Group C
Set Group D
Setting change in progress
Setting group A is active
Setting group B is active
Setting group C is active
Setting group D is active
141
143
144
145
24V Failure
15V Failure
5V Failure
Offset Fail
Failure of internal 24VDC power supply
Failure of internal 15VDC power supply
Failure of internal 5VDC power supply
Offset failure (A/D converter)
151
152
I/O 1 Failure
I/O 2 Failure
Failure in I/O module 1
Failure in I/O module 2
161
163
I Supervision
Failure I symm
Failure: Current supervision
Failure: Current symmetry supervision
356 >Manual Close Manual Close command
391
392
393
>Buchh. Warn
>Buchh. Trip
>Buchh. Tank
Warning stage from Buchholz protection
Tripping stage from Buchholz protection
Tank Supervision from Buchholz protection
501
511
Relay Pick
-
up
Trip
Relay Pick
-
up
General trip of the relay
561 M/C Detect Manual close command
571
572
573
Fail. I sym 1
Fail. I sym 2
Fail. I sym 3
Fail: Current symm. supervision Side 1
Fail: Current symm. supervision Side 2
Fail: Current symm. supervision Side 3
