14
Operation Using the Front Panel Controls
7UT51 v3
146 PRIM-2330C
14.5.2 Clearing a Log
Follow these steps to reset the Event Log and/or Fault
Logs:
1. Enter the password (000000).
2. Go to Address 8202 to reset the Event/
Operational Log, or Address 8203 to reset the
fault logs.
3. Press the
YES
key.
In a moment, the message “
SUCCESSFUL
” will
appear.
14.6 Measured Values
Metered values are system data collected and
calculated by the relay. The relay can display metered
values on the front panel LCD, or export them to a
device connected to the relay through a serial port.
The display of metered values is updated every 1 to 5
seconds. The ability to check the relay’s metered
values is helpful during commissioning, normal
operation, and troubleshooting.
5700 Operational Metered Values
5900 Thermal Overload Protection Calculated Values
Metered values are stored in these address. They are updated every 1 – 5 seconds.
LCD Abbreviation Address Description
W1 Ia[%]=
W1 Ib[%]=
W1 Ic[%]=
5701
5702
5703
Current in winding (or side) 1 for phases A, B, and C as a percentage of the rated current.
W2 Ia[%]=
W2 Ib[%]=
W2 Ic[%]=
5704
5705
5706
Current in winding (or side) 2 for phases A, B, and C as a percentage of the rated current.
W3 Ia[%]=
W3 Ib[%]=
W3 Ic[%]=
5707
5708
5709
Current in winding (or side) 3 for phases A, B, and C as a percentage of the rated current
(7UT513 only).
IA[%]=
IB[%]=
5710
5711
Additional current inputs when used and assigned (7UT513 only).
W1 Ia=
W1 Ib=
W1 Ic=
5721
5722
5723
Current in winding (or side) 1 for phases A, B, and C in amps.
W2 Ia=
W2 Ib=
W2 Ic=
5724
5725
5726
Current in winding (or side) 2 for phases A, B, and C in amps.
W3 Ia=
W3 Ib=
W3 Ic=
5727
5728
5729
Current in winding (or side) 3 for phases A, B, and C in amps (7UT513 only).
IA=
IB=
5730
5731
Additional current inputs when used and assigned in amps or milliamps, depending on how
configured (7UT513 only).
Θ1/Θtrp
Θ1/ΘtrpA
Θ1/ΘtrpB
Θ1/ΘtrpC
5911
5912
5913
5914
Temperature rise of 49
-
1 protection function for all phases, and separately for phases
A, B, and C.
Θ2/Θtrp
Θ2/ΘtrpA
Θ2/ΘtrpB
Θ2/ΘtrpC
5921
5922
5923
5924
Temperature rise of 49
-
2 protection function for all phases, and separately for phases
A, B, and C.
