14.7 Capturing Waveform Data
The relay can record waveform data for the time just
before, during, and just after a fault. While this data
cannot be viewed on the front panel LCD, it can be
exported to a PC for analysis and viewing. The
sampling rate is 12 samples per power cycle. Data for
up to 3 faults is stored.
The storage of waveform data can be initiated in four
ways: (1) by the pickup of any active protection
function, (2) by the trip of any active protection
function, (3) by an external signal-contact input, or (4)
by a manual command using the front panel keypad.
The waveform recording-time period is divided into
three parts: the
pre
-
time
, the
middle
-
time
, and the
post
-
time
. The middle-time period begins when an
event initiates a fault log (a pickup, trip, contact-input,
or keypad-input). The middle-time ends with the
dropout of the protection function (for internally
initiated recordings), after a specified time period (for
recordings initiated by a signal-contact or a
keypad-input), or the external signal-input ends (an
option for recordings initiated by a signal-contact
input).
5700 Operational Metered Values
5900 Thermal Overload Protection Calculated Values
Metered values are stored in these address. They are updated every 1 – 5 seconds.
LCD Abbreviation Address Description
W1 Ia[%]=
W1 Ib[%]=
W1 Ic[%]=
5701
5702
5703
Current in winding (or side) 1 for phases A, B, and C as a percentage of the rated current.
W2 Ia[%]=
W2 Ib[%]=
W2 Ic[%]=
5704
5705
5706
Current in winding (or side) 2 for phases A, B, and C as a percentage of the rated current.
W3 Ia[%]=
W3 Ib[%]=
W3 Ic[%]=
5707
5708
5709
Current in winding (or side) 3 for phases A, B, and C as a percentage of the rated current
(7UT513 only).
IA[%]=
IB[%]=
5710
5711
Additional current inputs when used and assigned (7UT513 only).
W1 Ia=
W1 Ib=
W1 Ic=
5721
5722
5723
Current in winding (or side) 1 for phases A, B, and C in amps.
W2 Ia=
W2 Ib=
W2 Ic=
5724
5725
5726
Current in winding (or side) 2 for phases A, B, and C in amps.
W3 Ia=
W3 Ib=
W3 Ic=
5727
5728
5729
Current in winding (or side) 3 for phases A, B, and C in amps (7UT513 only).
IA=
IB=
5730
5731
Additional current inputs when used and assigned in amps or milliamps, depending on
how configured (7UT513 only).
Θ1/Θtrp
Θ1/ΘtrpA
Θ1/ΘtrpB
Θ1/ΘtrpC
5911
5912
5913
5914
Temperature rise of 49
-
1 protection function for all phases, and separately for phases
A, B, and C.
Θ2/Θtrp
Θ2/ΘtrpA
Θ2/ΘtrpB
Θ2/ΘtrpC
5921
5922
5923
5924
Temperature rise of 49
-
2 protection function for all phases, and separately for phases
A, B, and C.
