14
Operation Using the Front Panel Controls
7UT51 v3
142 PRIM-2330C
4. If a correct password has been entered, the LCD
displays a confirmation message that the
password has been accepted:
If the wrong password has been entered, the
dialog box displays the following message:
Begin again with Step 2.
5. When the confirmation message appears, press
the
Enter
key. The display returns to the
Address where you were before you pressed the
Password
key.
If you change a value or choice stored in an
Address and then press or to scroll out of the
Address block, the LCD may ask if you want to exit
Password mode. Press
No
to continue selecting
addresses and perhaps make other changes, or press
Yes
if you are done making changes. If you press
Yes
,
the LCD will ask if you want to save the change(s) you
have made. Press
Yes
to save the change(s), or press
No
to abandon the change(s). In either case, you exit
Password mode and will have to re-enter the
password before making further changes.
14.3.2 Changing an Entered Value
To change the content of an Address which contains
an entered value, do the following:
1. If the relay is not already in password mode, enter
the password.
2. Enter or select the Address whose content you
want to change. The existing value will be
displayed.
3. Use the number keys to enter the new value, then
press the
Enter
key. (The backspace key enables
you to move to the left and re-enter a digit.)
The new value will be displayed. If the value
you entered is outside the allowed range for
that address’s content, a “
Value Too Small
” or
“
Number Too Big
” message will appear.
Re-enter an allowed value, or press
Enter
to
cancel the change and keep the existing
value.
4. If you wish, change other values or choices in
other addresses.
5. When done, press the
F
key, then the
Enter
key.
The LCD will ask if you want to save the changes.
Press
Yes
to save the change(s), or press
No
to
abandon the change(s). In either case, you exit
password mode and will have to re-enter the
password before making further changes.
14.3.3 Changing a Setting
Selected from a List
To change the content of an Address that contains a
selection from a list of options, do the following:
1. If the relay is not already in password mode, enter
the password.
2. Enter or select the Address whose content you
want to change. The existing selected option will
be displayed.
3. To change the existing selection, press
No
until
the option you want is displayed, then press
Yes
.
4. If you wish, change other values or options in
other addresses.
5. When done, press
F
, then
Enter
. The LCD will ask
if you want to save the changes. Press
Yes
to
save the change(s), or press
No
to abandon the
change(s). In either case, you exit password mode
and will have to re-enter the password before
making further changes.
14.3.4 Changing a Control
Configuration Option
To change a control configuration option or an LED
configuration, do the following:
1. If the relay is not already in password mode, enter
the password.
2. Enter or select the Address whose content you
want to change.
3. Press
F
and to get to the submenu of possible
options.
ENTER PASSWORD
PW ACCEPTED
ENTER PASSWORD
INVALID PASSWORD
