14 Operation Using the Front Panel Controls
7UT51 v3
144 PRIM-2330C
Change
-
over of the Active Parameter Set via
Binary Inputs
If change-over of parameter sets is intended to be
carried out via binary inputs, the following should be
followed:
• Activation must be switched to
Set By Bin Inputs
• Two logical binary inputs are available for control
of the 4 parameter sets. These binary inputs are
designated of “ParamSelec. 1” (Event 7) and
“ParamSelec. 2”, (Events 8).
• The logical binary inputs must be allocated to two
physical input modules in order to allow control.
An input is treated as not energized when it is not
assigned to any physical input.
• The control input signals must be continuously
present as long as the selected parameter set is
active.
The active parameter sets are assigned to the logical
binary inputs as shown in Table 14.1
Table 14.1
Parameter Set Change Via Binary Input
14.4.3 Copying a Group’s
Contents
Since you often will have settings groups that are
similar, the relay provides a way to copy the contents
of one setting group into another.
To copy the contents of one set into another, do the
following:
1. If the relay is not already in password mode, enter
the password.
2. Select one of the following addresses:
3. Press
Yes.
The message IN PROGESS will appear, followed by
the word
Successful
.
Binary Input
>ParamSelec. 1 >ParamSelec. 2 Causes Active Set
no no Set A
yes no Set B
no yes Set C
yes yes Set D
8510 COPY ORIG.SET
-
>SET A
8511 COPY ORIG.SET
-
>SET B
8512 COPY ORIG.SET
-
>SET C
8513 COPY ORIG.SET
-
>SET D
8514 COPY SET A
-
> SET B
8515 COPY SET A
-
> SET C
8516 COPY SET A
-
> SET D
8517 COPY SET B
-
> SET A
8518 COPY SET B
-
> SET C
8519 COPY SET B
-
> SET D
8520 COPY SET C
-
> SET A
8521 COPY SET C
-
> SET B
8522 COPY SET C
-
> SET D
8523 COPY SET D
-
> SET A
8524 COPY SET D
-
> SET B
8525 COPY SET D
-
> SET C
Select one of these addresses and press
Yes to perform the corresponding copying
of a settings group’s contents.
To Next Page
