Siemens 7UT51

7UT51 v3
Operation Using a Personal Computer
15
PRIM-2330C 155
Configuration of Communications Port
(Address Block 7200)
The device provides one or two serial interfaces: one
PC interface in the front for operation by means of a
PC and depending on the model ordered, another
system interface for connection of a central control
and storage unit, for example Siemens LSA 678.
Communication via these interfaces requires some
configured settings: identification of the relay,
transmission format, and transmission speed.
• 7209 DEVICE. TYPE
- Identifies the device type of the relay to
Siemens LSA systems and to WinDIGSI
software. Usually this setting should not be
changed.
• 7211 FRONT PORT
- Data format for communication via the
front-panel data port.
• 7215 FRONT BAUD
- Data transmission rate for front-panel data
port.
•7216FRT. PARITY
- Data parity setting for front-panel data port.
• 7221 REAR PORT
- Data format for communication of Operational
Log and fault logs via the rear data port (on
the back of the relay case).
• 7222 REAR FORMAT
- Data format for communication of measured
values via the rear data port (on the back of
the relay case).
• 7225 REAR BAUD
- Data transmission rate for rear data port (on
the back of the relay case).
• 7226 REAR PARITY
- Data parity setting for rear data port (on back
of the relay case).
• 7235 PROGviaREAR
- Choice of whether relay will allow
configuration via the rear data port (on the
back of the relay case).
Wave Capture (Address Block 7400)
• Address 7402 – Trigger for waveform capture
• Address 7410 – Max length of a waveform capture
record
• Address 7411 – Amount of captured waveform
prior to trigger
• Address 7412 – Amount of captured waveform
after trigger
• Address 7431 – Discrete input initiated waveform
capture time
• Address 7432 – Keyboard initiated waveform
capture duration
• Address 7490 – Length of fault log (for previous
LSA)
Device Options (Address Block 7800)
• Address 7801 – Selection of the protected object
• Address 7806 – Selection of transformer A star
point
• Address 7807 – Selection of transformer B star
point
• Address 7816 – 87-State of the differential
protection
• Address 7819 – Restricted ground-fault protection
• Address 7821 – Backup overcurrent protection
• Address 7824 – 49-Thermal overload protection 1
• Address 7825 – 49-Thermal overload protection 2
• Address 7830 – State of external trip function 1
