Operation Using the Front Panel Controls
7UT51 v3
150 PRIM-2330C
5000
EVENT DATA Data available about events (faults) (5100
-
5900)
5100
EVENT LOG Event (fault) log
5200
LAST FAULT Data of the most recent event (fault) including time stamp and applicable alarms
5300
2nd TO LAST FAULT Data of the2nd most recent event (fault) including time stamp and applicable
alarms
5400
3rd TO LAST FAULT Data of the 3rd most recent event (fault) including time stamp and applicable
alarms
5700
METERING Data from metering functions
5900
MEASURED OVERLOAD
VALUE
Data from predefined overload values.
6000
CONFIGURATION Matrix settings connecting inputs to outputs (6100
-
6900)
6100
CONFIGURING DISCRETE
INPUTS
Settings for the contact inputs
6200
CONFIGURING SIGNAL
RELAYS
Settings for the output contacts
6300
CONFIGURING LEDs Settings for the LEDs on the front panel
6400
CONFIGURING TRIP
CONTACTS
Settings for the trip contacts
7000
DEVICES CONFIGURATION Settings for the relay and interfaces to other systems (7100
-
7900)
7100
LOCAL USER INTERFACE Settings for the front panel display
7200
SERIAL COMM
CONFIGURATION
Settings for serial communication (RS
-
232) at the front port
7400
WAVEFORM CAPTURE Data from the waveform capture function
7800
DEVICE OPTIONS Settings for the relay
8000
OTHER OPTIONS Optional settings for the relay (8100
-
8900)
8100
DATE AND TIME Date and time for the relay
8200
RESETTING STORED DATA How and when to reset stored data in the relay
8300
REAR FORMAT Settings for the rear port for network communications
8500
SETTING GROUP OPTIONS Optional settings for a group of protection settings
Block Function (LCD Text) Description
