Siemens 7UT51

20
Settings Record
7UT51 v3
216 PRIM-2330C
1626
87HS DELAY
87
-
Op time of high
-
set diff. curr stage
0.00
-
60.00 s or ∞ 0.00
1627
87 RESET
87
-
Reset dly after diff op has been initiated
0.00
-
60.00 s 0.10
1700
87
-
MOTOR/GENERATOR DIFF PROTECTION DATA
Password level = 2
1701
87 STATUS
87
-
State of differential protection
OFF X
ON
Block Tripping
1703
87 PICKUP
87
-
Pick
-
up value of diff protection
0.05
-
2.00 I/In M/G 0.10
1706
87SLOPE 1
87
-
Slope 1 of operating characteristic
0.10
-
0.50 0.12
1707
87BASE PT2
87
-
Base point for slope 2 of oper charact.
0.0
-
10.0 I/In M/G 2.5
1708
87SLOPE 2
87
-
Slope 2 of operating characteristic
0.25
-
0.95 0.50
1717
T
-
SAT
-
BLK
87
-
Max. blocking time at CT saturation
2
-
250 cycles or ∞ 8
1718
SAT
-
RESTR.
87
-
Min. restr. current for block at CT satur.
5.00
-
15.00 I/In M/G 7.00
1725
87 DELAY
87
-
Oper time delay of differential
protection
0.00
-
60.00 s or ∞ 0.00
1727
87 RESET
87
-
Reset delay after trip has been initiated
0.00
-
60.00 s 0.10
1800
87
-
TIE POINT DIFFERENTIAL PROTECTION DATA
Password level = 2.
1801
87 STATUS
87
-
State of differential protection
OFF X
ON
Block Tripping
1803
87 PICKUP
87
-
Pick
-
up value of diff protection
0.30
-
2.50 I/In Junct 1.00
1806
87SLOPE 1
87
-
Slope 1 of operating characteristic
0.10
-
0.50 0.25
1807
87BASE PT2
87
-
Base point for slope 2 of operating char
0.0
-
10.0 I/In Junct 2.5
1808
87SLOPE 2
87
-
Slope 2 of operating characteristic
0.25
-
0.95 0.50
1817
T
-
SAT
-
BLK
Max. blocking time at CT saturation
2
-
250 cycles or ∞ 8
1818
SAT
-
RESTR.
87
-
Min. restr. current for blocking @CT
satur.
5.00
-
15.00 I/In
Junct
7.00
1825
87
-
DELAY
87
-
Oper time delay of differential
protection
0.00
-
60.00 s or ∞ 0.00
1827
87
-
RESET
87
-
Reset delay after trip has been
initiated
0.00
-
60.00 s 0.10
1831
87 MON PU
87
-
Pick
-
up value of diff. current monitoring
0.15
-
0.80 I/In Junct 0.20
1832
87 MON DLY
87
-
Time delay of blocking by monitoring
1
-
10 s or ∞ 2
Addr
LCD Line 1
WinDIGSI Description
Options or
Range and Unit
Default
Setting
Group A
Setting
Group B
Setting
Group C
Setting
Group D
