© 2008 Siemens Energy & Automation, Inc. All Rights Reserved.
ACCESS 9340 and 9360 Meters PMCM-9340D-0208
Chapter 3—Operation 2/2008
EN–26
Advanced Meter Setup Options
To setup the advanced meter options, do the following:
1. Scroll through the Level 1 menu list until you see MAINT.
2. Press MAINT.
3. Press SETUP.
4. Enter your password.
NOTE: The default password is 0000.
5. Press
###: until ADVAN (advanced setup) is visible.
6. Press ADVAN.
Follow the directions in the following sections to set up the meter.
Set Up the Phase Rotation
1. Press ###: until ROT (phase rotation) is
visible.
2. Press ROT.
3. Select the phase rotation: ABC or CBA.
4. Press OK.
5. Press
1; until you are asked to save your
changes.
6. Press YES to save the changes.
PLSD110203
