ACCESS 9340 and 9360 Meters PMCM-9340D-0208
Appendix A—Meter Register List 2/2008
EN–122
Register List
Table A–3: Abbreviated Register List
Reg Name Scale Units Range Notes
1s Metering
1s Metering — Current
1100 Current, Phase A A Amps/Scale 0 – 32,767 RMS
1101 Current, Phase B A Amps/Scale 0 – 32,767 RMS
1102 Current, Phase C A Amps/Scale 0 – 32,767 RMS
1103 Current, Neutral B Amps/Scale
0 – 32,767
(-32,768 if N/A)
RMS (4-wire system only)
1105
Current, 3-Phase
Average
A Amps/Scale 0 – 32,767 Calculated mean of Phases A, B & C
1107
Current, Unbalance,
Phase A
— 0.10% 0 – 1,000
1108
Current, Unbalance,
Phase B
— 0.10% 0 – 1,000
1109
Current, Unbalance,
Phase C
— 0.10% 0 – 1,000
1110
Current, Unbalance,
Max
— 0.10% 0 – 1,000 Percent Unbalance, Worst
1s Metering — Voltage
1120 Voltage, A-B D Volts/Scale 0 – 32,767 RMS Voltage measured between A & B
1121 Voltage, B-C D Volts/Scale 0 – 32,767 RMS Voltage measured between B & C
1122 Voltage, C-A D Volts/Scale 0 – 32,767 RMS Voltage measured between C & A
1123 Voltage, L-L Average D Volts/Scale 0 – 32,767 RMS 3 Phase Average L-L Voltage
1124 Voltage, A-N D Volts/Scale
0 – 32,767
(-32,768 if N/A)
RMS Voltage measured between A & N
4-wire system, system 10, and system 12
1125 Voltage, B-N D Volts/Scale
0 – 32,767
(-32,768 if N/A)
RMS Voltage measured between B & N
4-wire system and system 12
1126 Voltage, C-N D Volts/Scale
0 – 32,767
(-32,768 if N/A)
RMS Voltage measured between C & N
4-wire system only
1127 Voltage, N-R E Volts/Scale
0 – 32,767
(-32,768 if N/A)
RMS Voltage measured between N & meter
reference
4-wire system with 4 element metering only
1128 Voltage, L-N Average D Volts/Scale 0 – 32,767
RMS 3-Phase Average L-N Voltage (2-phase
average for system 12)
1129
Voltage, Unbalance, A-
B
— 0.10% 0 – 1,000 Percent Voltage Unbalance, Phase A-B
1130
Voltage, Unbalance, B-
C
— 0.10% 0 – 1,000 Percent Voltage Unbalance, Phase B-C
1131
Voltage, Unbalance, C-
A
— 0.10% 0 – 1,000 Percent Voltage Unbalance, Phase C-A
1132
Voltage, Unbalance,
Max L-L
— 0.10% 0 – 1,000 Percent Voltage Unbalance, Worst L-L
