© 2008 Siemens Energy & Automation, Inc. All Rights Reserved.
PMCM-9340D-0208 ACCESS 9340 and 9360 Meters
2/2008 Chapter 1—Introduction
EN–9
Features
Table 1–7: ACCESS 9340/9360 Features
9340 9360
True rms metering to the 63rd harmonic
99
Accepts standard CT and PT inputs
99
600 volt direct connection on voltage inputs
99
High accuracy — 0.075% current and voltage (typical conditions)
99
Min/max readings of metered data
99
Input metering (five channels) with 9340-60-I/O26, or 9340-60-I/O2222 installed
99
Power quality readings — THD
99
Downloadable firmware
99
Easy setup through the integrated or remote display (password protected)
99
Setpoint-controlled alarm and relay functions
99
Onboard alarm logging
99
Wide operating temperature range: –25° to +70°C for the meter unit
99
Communications:
Onboard: one Modbus RS485 (2-wire)
9340-DISPKIT or 9360-DISPKIT: one configurable Modbus RS232/RS485 (2- or
4-wire)
9
9
9
9
Active energy accuracy: IEC 62053-22 and ANSI C12.20 Class 0.5S
99
Nonvolatile clock
99
Onboard data logging 80 KB 800 KB
Real-time harmonic magnitudes and angles (I and V):
To the 31st harmonic
To the 63rd harmonic
9
—
—
9
Waveform capture
Standard
Advanced
—
—
9
9
EN50160 evaluations —
9
Current and voltage sag/swell detection and logging —
9
