ACCESS 9340 and 9360 Meters PMCM-9340D-0208
Chapter 4—Metering Capabilities 2/2008
EN–44
Demand Readings
The meter provides a variety of demand readings, including
coincident readings and predicted demands. Table 4–2 lists the
available demand readings and their reportable ranges.
Table 4–2: Demand Readings
Demand Readings Reportable Range
Demand Current, Per-Phase, 3Ø Average, Neutral
Last Complete Interval
Peak
0 to 32,767 A
0 to 32,767 A
Average Power Factor (True), 3Ø Total
Last Complete Interval
Coincident with kW Peak
Coincident with kVAR Peak
Coincident with kVA Peak
–0.002 to 1.000 to +0.002
–0.002 to 1.000 to +0.002
–0.002 to 1.000 to +0.002
–0.002 to 1.000 to +0.002
Demand Real Power, 3Ø Total
Last Complete Interval
Predicted
Peak
Coincident kVA Demand
Coincident kVAR Demand
0 to ± 3276.70 MW
0 to ± 3276.70 MW
0 to ± 3276.70 MW
0 to ± 3276.70 MVA
0 to ± 3276.70 MVAR
Demand Reactive Power, 3Ø Total
Last Complete Interval
Predicted
Peak
Coincident kVA Demand
Coincident kW Demand
0 to ± 3276.70 MVAR
0 to ± 3276.70 MVAR
0 to ± 3276.70 MVAR
0 to ± 3276.70 MVA
0 to ± 3276.70 MW
Demand Apparent Power, 3Ø Total
Last Complete Interval
Predicted
Peak
Coincident kW Demand
Coincident kVAR Demand
0 to ± 3276.70 MVA
0 to ± 3276.70 MVA
0 to ± 3276.70 MVA
0 to ± 3276.70 MW
0 to ± 3276.70 MVAR
