HMI menu ID Parameter Description Default value
[unit]
Value range Access
level
3.4.1.2 Pickup S1 amplitude Measured signal level at pick-up
1. The amplitude on pick-up 1
and pick-up 2 should not differ‐
entiate more than 2 mV.
[mV] Read
only
3.4.1.3 Pickup S2 amplitude Measured signal level at pick-up
2. The amplitude on pick-up 1
and pick-up 2 should not differ‐
entiate more than 2 mV.
[mV] Read
only
3.4.1.4 Max. pickup amplitude
diff
Maximum allowed difference be‐
tween Pickup S1 and Pickup S2.
[V] Read
only
3.4.1.5 Sensor frequency The resonant frequency of the
sensor. The frequency depends
on sensor size and liquid density.
[Hz] Read
only
3.4.1.6 Offset Zero-point offset compensates
for sensor variation due to proc‐
ess conditions.
[kg/h] Read
only
3.4.2 Temperature monitoring
3.4.2.1.1 Current value The measured medium temper‐
ature in the tube.
[°C] Read
only
3.4.2.2 Transmitter electronics temperature
3.4.2.2.1 Current value The measured internal tempera‐
ture of the transmitter.
[°C] Read
only
3.4.2.2.2 Minimum [°C] Read
only
3.4.2.2.3 Timestamp at minimum Timestamp when minimum val‐
ue was measured
3.4.2.2.4 Maximum [°C] Read
only
3.4.2.2.5 Timestamp at maximum Timestamp when maximum val‐
ue was measured
3.4.2.3 DSL temperature
3.4.2.3.1 Current value The measured internal tempera‐
ture of the DSL.
[°C] Read
only
3.4.2.4 Sensor frame temperature
3.4.2.4.1 Current value The measured temperature of
the sensor frame.
[°C] Read
only
3.4.3 Inputs and outputs
3.4.3.1 Channel 1 – output with HART
3.4.3.1.1 Loop Current [mA]
Default settings
B.9 Maintenance and diagnostics
