Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no.
Operating line
791 Optimum stop control max
800 Reduced setp increase start
801 Reduced setp increase end
809 Continuous pump operation
No ¦ Yes
820 Overtemp prot pump circuit
Off ¦ On
830 Mixing valve boost
832 Actuator type
2-positioin ¦ 3-position
833 Switching differential 2-pos
834 Actuator running time
835 Mixing valve Xp
836 Mixing valve Tn
850 Floor curing function
Off ¦ Functional heating ¦ Curing heating ¦ Functional/curing heating ¦ Curing/functional heating ¦ Manually
851 Floor curing setp manually
861 Excess heat draw
Off ¦ Heating mode ¦ Always
870 With buffer
No ¦ Yes
872 With prim contr/system pump
No ¦ Yes
880 Pump speed reduction
Operating level ¦ Characteristic ¦ Temp differential nominal
881 Starting speed
882 Pump speed min
883 Pump speed max
888 Curve readj at 50% speed
889 Filter time const speed ctrl
890 Flow setp readj speed ctrl
No ¦ Yes
898 Operating level changeover
Frost protection ¦ Reduced ¦ Comfort
900 Optg mode changeover
None ¦ Protection ¦ Reduced ¦ Comfort ¦ Automatic
Cooling circuit 1
904 Protection setpoint
932 Room temp limitation
Heating circuit 2
1010 Comfort setpoint
1012 Reduced setpoint
1014 Frost protection setpoint
1016 Comfort setpoint max
1020 Heating curve slope
1021 Heating curve displacement
1026 Heating curve adaption
Off ¦ On
1030 Summer/winter heating limit
1032 24-hour heating limit
1033 Ext’n 24-hour heating limit
No ¦ Yes
1040 Flow temp setpoint min
