447/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no.
Operating line
1041 Flow temp setpoint max
1042 Flow temp setpoint room stat
1046 Delay heat request
1050 Room influence
1060 Room temp limitation
1061 Heating limit room controller
1070 Boost heating
1080 Quick setback
Off ¦ To Reduced setpoint ¦ To frost Prot setpoint
1090 Optimum start control max
1091 Optimum stop control max
1100 Reduced setp increase start
1101 Reduced setp increase end
1109 Continuous pump operation
No ¦ Yes
1120 Opertemp prot pump circuit
Off ¦ On
1130 Mixing valve boost
1132 Actuator type
2-position ¦ 3-position
1133 Switching differential 2-pos
1134 Actuator running time
1135 Mixing valve Xp
1136 Mixing valve Tn
1150 Floor curing function
Off ¦ Functional heating ¦ Curing heating ¦ Functional/curing heating ¦ Curing/functional heating ¦ Manually
1151 Floor curing setp manually
1161 Excess heat draw
Off ¦ Heating mode ¦ Always
1170 With buffer storage tank
No ¦ Yes
1172 With prim contr/system pump
No ¦ Yes
1180 Pump speed reduction
Operating level ¦ Characteristic ¦ Temp differential nomial
1181 Starting speed
1182 Pump speed min
1183 Pump speed max
1188 Curve readj at 50% speed
1189 Filter time constant speed ctrl
1190 Flow setp readj speed ctrl
No ¦ Yes
1198 Operating level changeover
Frost protection ¦ Reduced ¦ Comfort
1200 Optg mode changeover
None ¦ Protection ¦ Reduced¦ Comfort ¦ Automatic
Heating circuit 3
1310 Comfort setpoint
1312 Reduced setpoint
1314 Frost protection setpoint
1316 Comfort setpoint max
1320 Heating curve slope
1321 Heating curve displacement
1326 Heating curve adaption
