Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
The Chimney sweep function is automatically deactivated when the boiler temperature
reaches the switch-off point.
Note!
If dynamic switching limits are activated (Dyn SD on setpoint (2464), Min setpoint
change dyn SD (2465), Dyn SD with HC/DHW change (2466) and Dyn SD when
burner on (2467)), they also apply to the Chimney sweep function .
The burner’s output during the time the Chimney sweep function is active can be set:
 Low-fire: Chimney sweep function with minimum boiler output
 High-fire: Chimney sweep function with maximum boiler output
 Maximum heating load: Chimney sweep function with parameterized maximum
boiler output
Note!
When pressing the manual control button during the time the Chimney sweep
function is active, the function is aborted and a change to manual control is made.
The function is automatically aborted after a timeout of 1 hour, provided the switch-off
point for automatic shutdown is not reached during that period of time.
Key
Line no. Meaning
2212 Maximum setpoint
2454 Switching differential when heating circuits On
2455 Minimum switching differential when heating circuits Off
2456 Maximum switching differential when heating circuits Off
Line no. Operating line
7131 Burner output
Partial load
Full load
Max heating load
Preset burner output for performing the Chimney sweep function.
Partial load
Operation of boiler at minimum output when the Chimney sweep function is activated.
Full load
Operation of boiler at maximum output when the Chimney sweep function is activated.
Max heating load
Operation of boiler at the parameterized maximum heating load when the Chimney
sweep function is activated.
Burner output
