Building Technologies Basic documentation LMV37.4... CC1P7546en
27 Parameter level 17.12.2018
Note
Ensure that the fuel train is correctly set in compliance with the type of burner used.
No. Parameter Actuator controlled
Air Fuel
201 Burner operating mode (fuel train, modulating / multistage,
actuators, etc.)
● ●
-- = undefined (delete curves)
● ●
1 = gas modulating (G mod)
● ●
2 = gas modulating with pilot valve 1 (Gp1 mod)
● ●
3 = gas modulating with pilot valve 2 (Gp2 mod)
● ●
4 = oil modulating (Lo mod)
● ●
5 = oil 2-stage (Lo 2 stage)
●
---
6 = oil 3-stage (Lo 3 stage)
●
---
7 = gas modulating pneumatic (G mod pneu)
●
---
8 = gas modulating pneumatic with pilot valve 1 (Gp1 mod
pneu)
●
---
9 = gas modulating pneumatic with pilot valve 2 (Gp2 mod
pneu)
●
---
10 = oil modulating with pilot valve (LoGp mod)
● ●
11 = oil 2-stage with pilot valve 2 (LoGp 2-stage)
●
---
12 = oil modulating with 2 fuel valves (Lo mod 2 fuel
valves)
● ●
13 = oil modulating with pilot valve and 2 fuel valves (LoGp
mod 2 fuel valves)
● ●
14 = gas modulating pneumatic without actuator (G mod
pneu without actuator, 0 active)
--- ---
15 = gas modulating pneumatic with pilot valve 1 without
actuator (Gp1 mod pneu without actuator, 0 active)
--- ---
16 = gas modulating pneumatic with pilot valve 2 without
actuator (Gp2 mod pneu without actuator, 0 active)
--- ---
17 = oil 2-stage without actuator (Lo 2-stage without
actuator, 0 active)
--- ---
18 = oil 3-stage without actuator (Lo 3-stage without
actuator, 0 active)
--- ---
19 = gas modulating only gas actuator (G mod only gas
actuator, fuel active)
---
●
20 = gas modulating with pilot valve 1 only gas actuator
(Gp1 mod only gas actuator, fuel active)
---
●
21 = gas modulating with pilot valve 2 only gas actuator
(Gp2 mod only gas actuator, fuel active)
---
●
22 = oil modulating only oil actuator (Lo mod only oil
actuator, fuel active)
---
●
23 = heavy oil modulating with circulation control (Ho mod
separate circulation control
● ●
24 = heavy oil 2-stage with circulation control (Ho 2 stage
separate circulation control
●
---
25 = heavy oil modulation without circulation control (Ho
mod without circulation control)
● ●
26 = heavy oil 2-stage without circulation control (Ho 2
stage without circulation control)
●
---
27 = heavy oil 3-stage without circulation control (Ho 3
stage without circulation control)
●
---
28 = gas modulating mechanical only air actuator (G mod
mech only fuel active, fuel active)
●
---
29 = gas modulating mechanical with pilot valve 2 only air
actuator (Gp2 mod mech only air actuator, fuel active)
●
---
