Building Technologies Basic documentation LMV37.4... CC1P7546en
28 Parameter list LMV37.4 17.12.2018
Par. Parameter Number of Type Edit Value range Increment Default Password level
no. elements Min. Max. setting write read
0 = CLOSED (<0°)
1 = OPEN (>90°)
602 Actuator's direction of rotation
Index 0 = fuel
Index 1 = air
Setting values:
0 = counterclockwise
1 = clockwise (exclusively for SQM3)
2 Selection edit 0 1 1 Index
0
1
Wert
0
0
OEM HF
606 Tolerance limit of position monitoring [0.1°]
Index 0 = fuel
Index 1 = air
Greatest position error where a fault is securely
detected
error detection band: (parameter 606 -0.6°) to
parameter 606
2 Std_u8 edit 0,5° 4° 0,1° Index
0
1
Wert
1,7°
1,7°
OEM HF
611 Type of reference
Index 0 = fuel
Index 1 = air
Setting values:
0 = standard
1 = range stop in the usable range
2 = internal range stop (SQN1)
3 = both
2 Std_u8 edit 0 3 1 Index
0
1
Wert
0
0
OEM HF
613 Type of actuator
Index 0 = fuel
Index 1 = air
Setting values:
0 = 5 s / 90° (1 Nm, 1,2 Nm, 3 Nm)
1 = 10 s / 90° (6 Nm)
2 = 17 s / 90° (10 Nm)
2 Std_u8 edit 0 2 1 0; 0 OEM HF
641 Activation of the speed standardization of VSD
Error diagnostics of negative values (refer to error
code 82)
0 = no speed standardization
1 Std_s8 edit -25 1 1 0 HF HF
