Building Technologies Basic documentation LMV37.4... CC1P7546en
28 Parameter list LMV37.4 17.12.2018
Par. Parameter Number of Type Edit Value range Increment Default Password level
no. elements Min. Max. setting write read
668 Maximum ignition speed 1 Std_s16 edit / clear 20% 75% 0,1% undefined OEM HF
669 Minimum / maximum speed limitation in operation
Index 0 = minimum speed
Index 1 = maximum speed
2 Std_s16 edit / clear 10% 100% 0,1% undefined OEM HF
670 Speed air pressure switch OFF 1 Std_s16 edit 20% 90% 0,1% 50% OEM HF
671 Speed air pressure switch ON 1 Std_s16 edit 45% 100% 0,1% 80% OEM HF
700 Error history
701 Current error state
701.01 Error code 25 Std_u8 read only 0 255 1 0 --- IS
701.02 Diagnostic code 25 Std_u8 read only 0 255 1 0 --- IS
701.03 Error class 25 Std_u8
read only
0 6 1 0 --- IS
701.04 Error phase 25 Std_u8
read only
0 255 1 0 --- IS
701.05 Startup counter 25 Std_s32
read only
0 99999999 1 0 --- IS
701.06 Output 25 Output
read only
0% 100% 0,1% 0% --- IS
702 Latest error in the history
725 Oldest error in the history
900 Process data
903 Current output
Index 0 = fuel
Index 1 = air
2 Output read only 0% 100% 0,1% 0% --- IS
For query
via
ACS410
916 Input value analog input
4 mA = 15%
10 mA = 0%
20 mA = 25%
1 Std_s16 read only -20% 30% 0,1% 0% --- HF (GA)
917 Target value trim function (with limitation and
damping)
1 Std_s16
read only
-17,5% 27,5% 0,1% 0% --- HF
918 Current trim correction 1 Std_s16
read only
-17,5% 27,5% 0,1% 0% --- HF (GA)
922 Incremental position of actuators
Index 0 = fuel
Index 1 = air
2 Std_s16
read only
-50° 150° 0,01° 0° --- IS
932 Speed specification of the frequency converter / fan 1 Std_s16
read only
0% 3276,7% 0,1% 0% --- HF
933 Offset from the VSD speed control 1 Std_s16
read only
-10% 15% 0,1% 0% --- HF
935 Absolute speed 1 Std_u16
read only
0 65535 0,1 0 --- HF (GA)
