Note
The IE Switches X-300 support "full wire speed switching" complying with IEEE 802.3 on all
ports. The number of packets therefore depends on the packet length.
Full wire speed switching
Number of frames per second At a frame length of
At 100 Mbps At 1000 Mbps
148810 1488095 64 bytes
84459 844595 128 bytes
45290 452899 256 bytes
23496 234962 512 bytes
11973 119732 1024 bytes
9615 96154 1280 bytes
8127 81274 1518 bytes
Note
The following applies to IE Switches X-300:
The number of IE Switches X-300 connected in a line influences the frame delay time. When
a frame passes through the switch, this is delayed by the Store&Forward function of the
IE Switch X-300 by the following values:
● at 64 bytes frame length: Delay of approx. 10 microseconds (at 100 Mbps)
● at 1500 bytes frame length: Delay of approx. 130 microseconds
(at 100 Mbps)
This means, the more IE Switches X-300 a frame runs through, the higher the frame delay.
PRP compatibility
Device variant As of version *
X304-2FE
X306-1LD FE
X307-3
X307-3LD
X308-2
X308-2LD
X308-2LH
X308-2LH+
X310
X310FE
X320-1 FE
X320-3LD FE
V3.7.0
* Information about the firmware version (V) as of which PRP is supported.
Technical specifications
8.2 X-300 technical specifications
SCALANCE X-300
160 Operating Instructions, 11/2019, A5E01113043-24
