Page #166 background image
Note
The following applies to IE Switches X-300:
The number of IE Switches X-300 connected in a line influences the frame delay time. When
a frame passes through the switch, this is delayed by the Store&Forward function of the
IE Switch X-300 by the following values:
at 64 bytes frame length: Delay of approx. 10 microseconds (at 100 Mbps)
at 1500 bytes frame length: Delay of approx. 130 microseconds
(at 100 Mbps)
This means, the more IE Switches X-300 a frame runs through, the higher the frame delay.
PRP compatibility
Device variant As of version *
X308-2M
X308-2M TS
V3.7.0
* Information about the firmware version (V) as of which PRP is supported.
Note
For a device to be used in PRP networks, it must be able to process a frame length of at least
1528 bytes (Jumbo Frames). This value is the maximum frame length including VLAN tag of
1522 bytes plus the length of the PRP trailer of 6 bytes. The following table shows the version
as of which the devices are PRP-compatible.
8.4 XR-300M technical specifications
Note
Validity of the technical specifications
All the technical specifications described in this section that is not assigned to a specific device
variant, version or a media module, apply to all device variants/versions of the product group.
8.4.1 Construction, installation and environmental conditions
Table 8-26 Construction
Device version
(power supply)
Dimensions (W x H x D) Weight Degree of protec‐
tion
2 x 24 VDC 483 × 44 × 305 mm 5500 g IP20
1 x 100 to 240 VAC 483 × 44 × 305 mm 5900 g IP20
Technical specifications
8.4 XR-300M technical specifications
SCALANCE X-300
166 Operating Instructions, 11/2019, A5E01113043-24
