Figure 4-10 SCALANCE X310
Column 1 2 3 4
Port number P1 P5 P8 P9
P2 P6 - P10
P3 P7 - -
P4 - - -
Connection
type
Electrical: Fast Ethernet Electrical: Gigabit Ethernet
4.4.1.10 SCALANCE X310FE product characteristics
Possible attachments
The SCALANCE X310FE provides the following options for the connection of end devices or
other network segments:
● 10 RJ-45 jacks
Description of the device
4.4 Product properties and device views
SCALANCE X-300
58 Operating Instructions, 11/2019, A5E01113043-24
