Full wire speed switching
Number of frames per second At a frame length of
At 100 Mbps At 1000 Mbps
148810 1488095 64 bytes
84459 844595 128 bytes
45290 452899 256 bytes
23496 234962 512 bytes
11973 119732 1024 bytes
9615 96154 1280 bytes
8127 81274 1518 bytes
Note
The following applies to IE Switches X-300:
The number of IE Switches X-300 connected in a line influences the frame delay time. When
a frame passes through the switch, this is delayed by the Store&Forward function of the
IE Switch X-300 by the following values:
● at 64 bytes frame length: Delay of approx. 10 microseconds (at 100 Mbps)
● at 1500 bytes frame length: Delay of approx. 130 microseconds (at 100 Mbps)
This means, the more IE Switches X-300 a frame runs through, the higher the frame delay.
PRP compatibility
Device variant As of version *
XR324-4M PoE V3.7.0
XR324-4M PoE TS V3.7.x
* Information about the firmware version (V) as of which PRP is supported.
Note
For a device to be used in PRP networks, it must be able to process a frame length of at least
1528 bytes (Jumbo Frames). This value is the maximum frame length including VLAN tag of
1522 bytes plus the length of the PRP trailer of 6 bytes. The following table shows the version
as of which the devices are PRP-compatible.
8.9 MM900 technical specifications
Note
Validity of the technical specifications
All the technical specifications described in this section that are not specific to a product
version, apply to the MM900 media module.
Technical specifications
8.9 MM900 technical specifications
SCALANCE X-300
Operating Instructions, 11/2019, A5E01113043-24 201
