Figure 4-9 SCALANCE X308-2LD
Column 1 2 3 4
Port number P1 P5 P8 P9
P2 P6 -
P3 P7 - P10
P4 - -
Connection
type
Electrical: Fast Ethernet
Electrical:
Gigabit Ethernet
Optical:
Gigabit Ethernet
4.4.1.9 SCALANCE X310 product characteristics
Possible attachments
The SCALANCE X310 provides the following options for the connection of end devices or other
network segments:
● 10 RJ-45 jacks
