PRP compatibility
Device variant As of version *
XR324-4M EEC V3.7.0
* Information about the firmware version (V) as of which PRP is supported.
Note
For a device to be used in PRP networks, it must be able to process a frame length of at least
1528 bytes (Jumbo Frames). This value is the maximum frame length including VLAN tag of
1522 bytes plus the length of the PRP trailer of 6 bytes. The following table shows the version
as of which the devices are PRP-compatible.
8.7 X-300M PoE technical specifications
Note
Validity of the technical specifications
All the technical specifications described in this section that is not assigned to a specific device
variant, version or a media module, apply to all device variants/versions of the product group.
8.7.1 Construction, installation and environmental conditions
Table 8-66 Construction
Dimensions (W x H x D) 120 × 125 × 124 mm
Weight 1150 g
Degree of protection IP20
Table 8-67 Installation options
Installation options
● DIN rail
1)
● S7-300 standard rail
● Wall
1)
Note: When used in shipbuilding, installation on a 35 mm DIN rail is not permitted. In ships, the 35 mm
DIN rail does not provide adequate support.
Technical specifications
8.7 X-300M PoE technical specifications
SCALANCE X-300
188 Operating Instructions, 11/2019, A5E01113043-24
