8.5.1 Construction, installation and environmental conditions
Table 8-38 Construction
Device version
(power supply)
Dimensions (W x H x D) Weight Degree of protec‐
tion
1 24 VDC power supply unit
● Without clip:
60 × 125 × 123 mm
● With clip:
216 × 203 × 99 mm
1800 g IP30
2 x 24 VDC power supply
units
● Without clip:
60 × 125 × 123 mm
● With clip:
216 × 203 × 99 mm
2030 g IP30
1 x power supply unit
100 to 240 VAC / 60 to 250
VDC
● Without clip:
60 × 125 × 123 mm
● With clip:
216 × 203 × 99 mm
1850 g IP30
2 x power supply units
100 to 240 VAC / 60 to 250
VDC
● Without clip:
60 × 125 × 123 mm
● With clip:
216 × 203 × 99 mm
2120 g IP30
Table 8-39 Installation options
Installation options
● DIN rail
● S7-300 standard rail
1)
● Wall
2)
● 19" rack
3)
1)
Possible only with adapter (must be provided by installers).
2)
Wall mounting possible with suitable wall support.
3)
With mounting support
Table 8-40 Permitted ambient conditions
Storage/transport tem‐
perature
Operating temperature Max. relative humidi‐
ty in operation at 25
°C
Max. ambient temperature
at operating altitude
-40 °C to +70 °C -40 °C to +70 °C
1)
<= 95% (no conden‐
sation)
Max. 65 ℃ as of 2000 m
Max. 60 ℃ as of 3000 m
1)
The IE Switch was type tested for 16 h at +85 °C.
Technical specifications
8.5 Technical specifications for X-300EEC
SCALANCE X-300
174 Operating Instructions, 11/2019, A5E01113043-24
