MM992-2SFP with Current consumption Effective power loss
SFP992-1LH 70 mA 1.71 W
SFP992-LH+ 80 mA 1.93 W
SFP992-1ELH 100 mA 2.31 W
SFP991-1ELH200 100 mA 2.31 W
Note
Fusing and signal contacts with media modules
The MM900 media modules do not have their own fuses and have no signaling contacts. The
fuses and the signaling contacts exist in the SCALANCE device.
Table 8-103 Electrical data: Transmitter output (optical) and receiver input
Media module Transmitter output (optical) Receiver input
min. [dBm] max. [dBm] Sensitivity min. [dBm] Input power max.
[dBm]
MM992-2CUC - - - -
MM992-2CUC (C) - - - -
MM992-2CU - - - -
MM992-2M12 (C)
2)
- - - -
MM992-2VD - - - -
MM991-2 (BFOC) -19 -14 -32 -3
MM991-2FM (BFOC) -19 -14 -32 -3
MM991-2LD (BFOC) -15 -8 -34 -3
MM991-2 (SC) -19 -14 -34 -3
MM991-2LD (SC) -15 -8 -32 -3
MM991-2LH+ (SC) -5 0 -34 -3
MM991-2P (SC RJ) -8 -2 -23 +1
MM992-2 (SC) -9.5 -4 -17 -3
MM992-2 (C) (SC) -9.5 -4 -17 -3
MM992-2LD (SC) -9.5 -3 -21 -3
MM992-2LH (SC) -6 0 -23 -3
MM992-2LH+ (SC) 0 5 -23 -3
MM992-2ELH (SC) 0 5 -30 -3
MM992-2SFP
1)
- - - -
1)
You will find further information in the compact operating instructions "Transceiver SFP/SFP
+".
2)
The ports of the MM992-2M12 (C) only meet the requirements according to Environment A
(IEEE 802.3), in other words, the electrical isolation of the ports is designed for 500 Vrms (1
minute).
Technical specifications
8.9 MM900 technical specifications
SCALANCE X-300
206 Operating Instructions, 11/2019, A5E01113043-24
