The parameters have the following meaning:
Parameter Description Range of values / note
trunk Configures the port as a trunk port that only forwards tagged
frames. The port can then only be configured as the trunk port
if the port is not entered in any VLAN that exchanges untagged
frames.
For the trunk port to forward tagged frames, all VLAN IDs to
which the trunk port forwards frames must be stored.
If a new VLAN is created, the VLAN ID is automatically entered
at the trunk port.
With a trunk port, the VLAN assignment is dynamic. Static
configurations can only be created if, in addition to the trunk
port property, the port is also entered statically as a member
in the VLANs involved. An example of a static configuration is
the assignment of the multicast groups in certain VLANs.
If you execute the "acceptable frame-type all" com‐
mand at the trunk port, the port also receives untagged frames.
-
hybrid Configures the port as a hybrid port that accepts tagged and
untagged frames.
Default: hybrid
Result
The operating mode is configured.
Further notes
You reset the operating mode to the default with the no switchport mode command.
You display this setting and other information with the show vlan port config command.
You configure the interface as a switch port with the switchport command.
6.1.3.8 no switchport mode
Description
With this command, you reset the operating mode for the switch port to the default.
The default value is Hybrid.
Requirement
● The interface is configured as a switch port.
● You are in the Interface configuration mode.
The command prompt is:
cli(config-if-$$$)#
Network structures
6.1 VLAN
SCALANCE XB-200/XC-200/XF-200BA/XP-200/XR-300WG Command Line Interface
184 Configuration Manual, 07/2017, C79000-G8976-C361-06
