Siemens SIMATIC ET 200SP User Manual

Product overview
3.6 Operator controls and display elements
CPU 1515SP PC (F)
Manual, 05/2017, A5E32701806-AC
27
Connector for supply voltage
CPU 1515SP PC (F) has a 2-pole terminal for the power supply.
The connection plug for the supply voltage is plugged in when the CPU is shipped from the
factory.
Mode selector
Use the mode selector to set the CPU operating mode.
Table 3- 3 Mode selector positions
Position
Meaning
Description
RUN
Operating mode RUN
1
The CPU is processing the user program.
STOP Operating mode STOP
1
The CPU is not processing the user program.
The outputs are set to a "safe" state.
MRES Memory reset
For active S7-1500 software controller
2
only:
CPU memory reset
1
RUN and STOP indicate the
selected
operating state. The LED displays RUN and STOP display the
actual
operating
state of the CPU 1515SP PC (F).
2
See the S7-1500 software controller manual

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
