Siemens SIMATIC S5 ET 200U User Manual

5-20
ET 200U Distributed I/O Station
EWA 4NEB 812 6087–02b
5.2 Starting Up and Testing with COM ET 200 for ET 200U(DP Standard)
This section describes
 How the station number and switch 8 are set ( Section 5.2.1)
 How you connect the ET 200U to the programmer ( Section 5.2.2)
and
 How you use the COM ET 200 “START–UP/TEST” screen
( Section 5.2.3).
In this Section
ET 200U(DP Standard): AddressAssignm.,Starting–Up, DiagnosingFaultsUsing COM ET 200

Siemens SIMATIC S5 ET 200U Specifications

General

Modularity	Modular
Supply voltage	24 V DC
Protection Class	IP20
Type	I/O System
Category	I/O Systems
Digital inputs	Available (number varies by module)
Digital outputs	Available (number varies by module)
Analog inputs	Available (number varies by module)
Analog outputs	Available (number varies by module)
Relative Humidity	5% to 95% (non-condensing)
Dimensions	Varies depending on module configuration
Weight	Varies depending on module configuration
