Siemens SIMATIC S5 ET 200U User Manual

4-28
ET 200U Distributed I/O Station
EWA 4NEB 812 6087–02b
COM ET 200 displays the following:
 The station number and the system name of the master station
 The firmware version of the IM 308–B interface module (in the master
station)
 The numbers of the stations for which diagnostics data is available
2. Press <F1> (CHANNEL DIAGNOST.)
Result: COM ET 200 asks for a station number.
3. In the STATION NUMBER input field, enter the number of the faulty
station that you want to investigate further.
4. Press <F6> (ENTER) to be able to evaluate the diagnostics messages of
this station.
Result: COM ET 200 goes to another screen. The screen that appears next
depends on the type of station you are investigating.
EXIT
F2 F3 F4 F5 F6 F7 F8F1
Station number: 123
Program file selected: TEST$$ET.200
SIMATIC S5 / COM ET 200
Individual Diagnostics
Station type: ET 200U
Station name: Test station 1
Configuration: Faulty modules are marked with ’*’
Station diagnostics: Parameterization error
0.
1.*
2.*
3. 4. 5.
6.
7.
8.
9.
10.
11. 12. 13.
14.
15
.
16.
17.
18.
19. 20. 21.
22.
23.
24.
25.
26.
27. 28. 29.
30.
31.
8DI
8DI 8DQ
8DQ
Figure 4-10 INDIVIDUAL DIAGNOSTICS Screen
ET 200U(DP Siemens): AddressAssignment,Starting–Up,Diagnosing Faults Using COMET200

Siemens SIMATIC S5 ET 200U Specifications

General

Modularity	Modular
Supply voltage	24 V DC
Protection Class	IP20
Type	I/O System
Category	I/O Systems
Digital inputs	Available (number varies by module)
Digital outputs	Available (number varies by module)
Analog inputs	Available (number varies by module)
Analog outputs	Available (number varies by module)
Relative Humidity	5% to 95% (non-condensing)
Dimensions	Varies depending on module configuration
Weight	Varies depending on module configuration
