Siemens SIMATIC TP 270 User Manual

Operate project
9.1 Basic principles of operation
TP 270, OP 270, MP 270B (WinCC flexible)
Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
9-13
Shortcut keys Function
F
N
+
END
Jumps to the end of a selection list.
SHIFT
+
F
N
+
HOME
Selects a group of entries between the current position and the top of the list.
SHIFT
+
F
N
+
END
Selects a group of entries between the current position and the end of the list.
ALT
+
Opens a selection list.
Monitor screen settings
Shortcut keys Function
A-Z
+
Increases the brightness of the monitor screen.
A-Z
+
Reduces the brightness of the monitor screen.
A-Z
+
Increases the screen contrast (OP 270 only).
A-Z
+
Reduces the screen contrast (OP 270 only).
In the startup phase
Shortcut keys Function
ESC
+
ESC
Toggles the HMI device to "transfer" mode.
You can always exit transfer mode provided the unit is currently not transferring any data.
Further functions (e.g. in the Explorer)
Shortcut keys Function
CTRL
+
ENTER
Accepts the selected entry without closing the list.
CTRL
+
TAB
• Toggles the active window.
• Toggles between the base area and the window.
CTRL
+
BA
Selects all (left letter assignment is active.)
ALT
+
ENTER
Shows the properties of a selected element.
